  • Finetuning Domain adaptive language model with FastTrack

    By Yonggeun Kwon

    Introduction

    This article explains how to train and evaluate a language model specialized in supply chain and trade-related domains using Backend.AI's MLOps platform, FastTrack. For this language model, we used the gemma-2-2b-it model as the base model, which was continually pretrained with supply chain and trade domain datasets. To train a model specialized in the Question Answering task, domain datasets collected and processed from the web were converted into a Q/A task format, consisting of trainable questions and answers, depending on the use case.

    Developing AI involves stages such as data preprocessing, training, validation, deployment, and inference. Using Lablup's FastTrack, each of these stages can be configured into a single pipeline, allowing for easy customization, such as skipping specific stages or adjusting resource allocation per stage according to the pipeline configuration.

    Concept of Domain Adaptation

    Before diving into model training, a process called Domain Adaptation is necessary. To briefly explain for those unfamiliar, Domain Adaptation refers to the process of refining a pretrained model to make it suitable for a specific domain. Most general-purpose language models we encounter today are not designed to possess expertise in specific fields. These models are typically trained using datasets from general domains to predict the next token effectively and then fine-tuned to fit overall usage directions.

    However, when creating a model for use in a specialized domain, training with general datasets is insufficient. For instance, a model trained in a general domain can understand contexts like "This movie was amazing," but it may struggle with sentences in the legal domain, such as "The court ordered the seizure of the debtor's assets," due to the lack of learning of specific terms and expressions used in each domain. Similarly, if a Q/A task is given, implementing it with general data might not be possible. To properly handle a Q/A task, a language model must be fine-tuned with domain-specific datasets trained for the Q/A task. This fine-tuning process allows the model to better understand the nuances of the task and effectively respond to domain-specific questions from the user.

    This article focuses on the process of developing a model specialized in Supply Chain Management (SCM) and trade domains. As shown in the above image, there is a significant difference between general domain terms like "movie" or "travel" and SCM-specific terms like "air waybill" or "payment manager." To bridge this gap, our goal today is to adjust the model using datasets from SCM and trade domains to enhance the model's understanding of these domains and accurately capture the context.

    In summary, Domain Adaptation is essentially a process of overcoming the gaps between different domains, enabling the model to perform better in new contexts.

    Train model from scratch vs DAPT

    So, why not train the model from scratch using datasets from the specific domain? While this is possible, it comes with several limitations. Training a model from scratch with domain-specific datasets requires extensive data and training because the model lacks both general domain knowledge and domain-specific expertise. Collecting datasets for general domain deep learning is already challenging, but gathering high-quality, domain-specific data is even more difficult. Even if data is collected, preprocessing it to fit model training can be time-consuming and costly. Therefore, training a model from scratch is more suitable for companies with abundant domain-specific data and resources.

    What if you want to develop a domain-adaptive model but don't have access to vast datasets or sufficient resources? In such cases, Domain-Adaptive Pre-Training (DAPT) can be an effective approach. DAPT involves continual pretraining of a model that has already been extensively trained on general domains with domain-specific datasets to develop a specialized model. Since this method builds upon a model that already possesses knowledge of general domains, it requires relatively less cost and fewer datasets compared to training a model from scratch.

    Development environment Setup

    1. Package Installation
    pip install bitsandbytes==0.43.2
pip install deepspeed==0.14.4
pip install transformers==4.43.3
pip install accelerate==0.33.0
pip install flash-attn==1.0.5
pip install xforms==0.1.0
pip install datasets==2.20.0
pip install wandb
pip install evaluate==0.4.2
pip install vertexai==1.60.0
pip install peft==0.12.0
pip install tokenizers==0.19.1
pip install sentencepiece==0.2.0
pip install trl==0.9.6
pip install bitsandbytes==0.43.2
pip install deepspeed==0.14.4
pip install transformers==4.43.3
pip install accelerate==0.33.0
pip install flash-attn==1.0.5
pip install xforms==0.1.0
pip install datasets==2.20.0
pip install wandb
pip install evaluate==0.4.2
pip install vertexai==1.60.0
pip install peft==0.12.0
pip install tokenizers==0.19.1
pip install sentencepiece==0.2.0
pip install trl==0.9.6
    1. Import Modules
    import os
import json
from datasets import load_from_disk, Dataset,load_dataset
import torch
from transformers import AutoTokenizer, AutoModelForCausalLM, Gemma2ForCausalLM, BitsAndBytesConfig, pipeline, TrainingArguments
from peft import LoraConfig, get_peft_model
import transformers
from trl import SFTTrainer
from dotenv import load_dotenv
import wandb
from huggingface_hub import login

    Dataset preparation

    The preparation of datasets should vary depending on the purpose of fine-tuning. In this article, since our goal is to train a model that can effectively respond to questions related to the trade domain, we decided to use datasets that we collected ourselves through web crawling. The datasets are categorized into three types: trade certification exam datasets, trade term-definition datasets, and trade lecture script datasets.

    1. Trade Certification Exam Data Set

    질문: 다음 중 우리나라 대외무역법의 성격에 대한 설명으로 거리가 먼 것을 고르시오. 1. 우리나라에서 성립되고 이행되는 대외무역행위는 기본적으로 대외무역법을 적용한다. 2. 타 법에서 명시적으로 대외무역법의 적용을 배제하면 당해 법은 특별법으로서 대외무역법보다 우선 적용된다. 3. 대외무역법은 국내법으로서 국민의 국내 경제생활에 적용되는 법률이기 때문에 외국인이 국내에서 행하는 무역행위는 그 적용 대상이 아니다. 4. 관계 행정기관의 장은 해당 법률에 의한 물품의 수출·수입 요령 그 시행일 전에 지식경제부 장관이 통합하여 공고할 수 있도록 제출하여야 한다. 정답: 대외무역법은 국내법으로서 국민의 국내 경제생활에 적용되는 법률이기 때문에 외국인이 국내에서 행하는 무역행위는 그 적용 대상이 아니다. 질문: ...

    1. Trade Terms Definition Data Set
    {
  "term": "(계약 등을) 완전 무효화하다, 백지화하다, (처음부터) 없었던 것으로 하다(Rescind)",
  "description": "계약을 파기, 무효화, 철회, 취소하는 것; 그렇지 않았음에도 불구하고 계약을 시작부터 무효인 것으로 선언하고 종결짓는 것."
}
    1. Trade Lecture Script Dataset

    예전에는 전자상거래 셀러가 엑셀에다가 입력을 해서 수출신고 데이터를 업로드 해서 생성을 했잖아요 그리고 대량으로 전송하는 셀러는 api를 통해서 신고를 했습니다 그런데 그 수출신고 정보의 원천정보를 뭐냐면 쇼핑몰에서 제공하는 판매 주문정보입니다 그래서 그 쇼핑몰에 직접 저희가 연계를 해서 판매 주문 정보를 가져올 수 있게끔 새 서비스를 만들었어요 그래서 API 연계된 쇼핑몰들이 있는데 그게 현재 5개가 연결되어 있는데 쇼피 쇼피파이 라자다 라쿠텐 q10이 있고요 아마존하고 위치도 연계 예정에 있습니다 그래서 셀러는 ...

    To create a model suitable for Q/A tasks, the datasets need to be converted into a question-and-answer format. The first dataset, the trade certification exam dataset, and the second dataset, the trade term-definition dataset, can be converted using simple code. However, upon examining the third dataset, the trade lecture script dataset, it appears challenging to directly convert the conversational data. In this case, an approach can be employed that uses large language models (LLMs) to extract Q/A pairs from the conversational scripts. The prompts and their results are as follows.

    Prompt

    summary: {summary}
Instruction: 다음 summary를 기반으로 질문과 해당 답변을 추출하세요.
출력 형식은 JSON으로, 각 질문과 답변을 객체로 묶어 'qa_pairs'라는 배열 안에 넣어야 합니다.
'questions' key에는 요약에서 도출된 질문 목록이 포함되어야 하며, 'answers' key에는 각 질문에 대한 해당 답변 목록이 포함되어야 합니다:
출력 예시:
{{"qa_pairs": [{{"question": "Question1", "answer": "Answer1"}},{{"question": "Question2", "answer": "Answer2"}},{{"question": "Question3", "answer": "Answer3"}},]...}}
Output:

    Output

    {"qa_pairs":
  [
    {"question": "전자상거래 무역 플랫폼은 어떤 서비스를 제공하나요?", "answer": "판매 주문 관리, 창고 관리, 수출입 통관, 배송 관리 등 전자상거래 업무를 위한 다양한 서비스를 제공합니다"},
    {"question": "쇼핑몰과의 API 연계를 통해 무엇을 간소화할 수 있나요?", "answer": "판매 주문 정보를 자동으로 가져와 수출신고를 간소화할 수 있습니다"},
    {"question": "창고 관리 기능은 어떤 것을 관리할 수 있나요?", "answer": "자가 창고, 위촉 창고, 해외 풀필먼트 센터 등을 관리할 수 있습니다"},
    {"question": "수출입 통관 서비스는 어떤 기능을 제공하나요?", "answer": "미국 세관과 연동된 수출입 통관 서비스를 통해 미국 수출 시 수입 신고를 간편하게 처리할 수 있습니다"},
    {"question": "배송 관리 기능은 어떤 서비스를 지원하나요?", "answer": "우체국 EMS, DHL 등 개별 배송과 함께 해외 현지 라스트 마일 배송까지 지원합니다"}
  ]
}

    It looks like we are now ready to convert each dataset into a Q/A dataset using simple code. Below is the code that demonstrates how to convert each dataset into Q/A format.

    import os
import json
import re
from datasets import Dataset, concatenate_datasets, load_from_disk

def replace_dot_number(text):
    result = re.sub(r'\.(\d+)\.', r'. \1.', text)
    return result

def read_json(path):
    with open(path, 'r', encoding='utf-8') as f:
        return json.load(f)

def write_json(data, path):
    with open(path, 'w', encoding='utf-8') as f:
        json.dump(data, f, ensure_ascii=False)

def dataset_maker(data:list) -> Dataset:
    return Dataset.from_list(data)

def save_dataset(dataset, save_path):
    dataset.save_to_disk(save_path)

def exam_qa_formatter():
    data = []
    root = 'dataset/exam_data'
    for file in sorted(os.listdir(root)):
        file_path = os.path.join(root, file)
        content = read_json(file_path)['fixed_text']
        question_list = content.split('질문:')[1:]
        for question in question_list:
            try:
                question_and_options = replace_dot_number(question.split('정답:')[0]).strip()
                answer = question.split('정답:')[1].strip()
                data.append({"context": replace_dot_number(question), "question":question_and_options, "answer":answer})

            except Exception as e:
                pass
    return data

def description_to_term_formattter(kor_term, eng_term, description):
    context = f"{kor_term}: {description}"
    question = f"설명: '{description}' 이 설명에 해당하는 무역 용어는 무엇인가요?"
    answer = kor_term if eng_term is None else f"{kor_term}, {eng_term}"
    return context, question, answer

def term_to_description(kor_term, eng_term, description):
    context = f"{kor_term}: {description}"
    question = f"'{kor_term}({eng_term})' 이라는 무역 용어는 어떤 의미인가요?" if eng_term is not None else f"'{kor_term}' 이라는 무역 용어는 어떤 의미인가요?"
    answer = description
    return context, question, answer

def term_qa_formatter():
    data = []
    root = 'dataset/term_data'
    for file in os.listdir(root):
        file_path = os.path.join(root, file)
        term_set = read_json(file_path)
        if file == 'terms_data_2.json':
            term_set = [item for sublist in term_set for item in sublist]
        for pair in term_set:
            eng_term = pair.get('eng_term', None)
            if 'term' in pair.keys():
                kor_term = pair['term']
            else:
                kor_term = pair['kor_term']
            description = pair['description']
            context_1, question_1, answer_1 = description_to_term_formattter(kor_term, eng_term, description)
            context_2, question_2, answer_2 = term_to_description(kor_term, eng_term, description)
            data_1 = {"context": context_1, "question": question_1, "answer": answer_1}
            data_2 = {"context": context_2, "question": question_2, "answer": answer_2}
            data.append(data_1)
            data.append(data_2)
    return data

def transcript_qa_formatter():
    data = []
    root = 'dataset/transcript_data/success'

    for file in sorted(os.listdir(root)):
        file_path = os.path.join(root, file)
        for line in open(file_path):
            line = json.loads(line)
            context = line['context']
            output = line['json_output']

            qa_pairs = json.loads(output)['qa_pairs']
            for pair in qa_pairs:
                question = pair['question']
                answer = pair['answer']
                if type(answer) == list:
                    answer = answer[0]
                data.append({"context": context, "question": question, "answer": answer})
    return data

    ###### Term dataset
{'context': 'APEC 경제위원회(Economic Committee (EC)): 개별위원회나 실무그룹이 추진하기 어려운 여러분야에 걸친 이슈에 대한 분석적 연구작업을 수행하기 위해 결성된 APEC 기구,',
 'question': "설명: '개별위원회나 실무그룹이 추진하기 어려운 여러분야에 걸친 이슈에 대한 분석적 연구작업을 수행하기 위해 결성된 APEC 기구,' 이 설명에 해당하는 무역 용어는 무엇인가요?",
 'answer': 'APEC 경제위원회(Economic Committee (EC))'}

###### Transcript dataset
{'context': '수입 신고는 일반적으로 입항 후에 하는 것이 원칙이며, 보세 구역에서 5부 10장을 작성하여 신고합니다',
 'question': '수입 신고는 언제 하는 것이 원칙인가요?',
 'answer': '수입 신고는 일반적으로 입항 후에 하는 것이 원칙입니다.'}

###### Exam dataset
{'context': ' 다음 중 우리나라 대외무역법의 성격에 대한 설명으로 거리가 먼 것을 고르시오. 1. 우리나라에서 성립되고 이행되는 대외무역행위는 기본적으로 대외무역법을 적용한다. 2. 타 법에서 명시적으로 대외무역법의 적용을 배제하면 당해 법은 특별법으로서 대외무역법보다 우선 적용된다. 3. 대외무역법은 국내법으로서 국민의 국내 경제생활에 적용되는 법률이기 때문에 외국인이 국내에서 행하는 무역행위는 그 적용 대상이 아니다. 4. 관계 행정기관의 장은 해당 법률에 의한 물품의 수출·수입 요령 그 시행일 전에 지식경제부 장관이 통합하여 공고할 수 있도록 제출하여야  한다.정답: 대외무역법은 국내법으로서 국민의 국내 경제생활에 적용되는 법률이기 때문에 외국인이 국내에서 행하는 무역행위는 그 적용 대상이 아니다.',
 'question': '다음 중 우리나라 대외무역법의 성격에 대한 설명으로 거리가 먼 것을 고르시오. 1. 우리나라에서 성립되고 이행되는 대외무역행위는 기본적으로 대외무역법을 적용한다. 2. 타 법에서 명시적으로 대외무역법의 적용을 배제하면 당해 법은 특별법으로서 대외무역법보다 우선 적용된다. 3. 대외무역법은 국내법으로서 국민의 국내 경제생활에 적용되는 법률이기 때문에 외국인이 국내에서 행하는 무역행위는 그 적용 대상이 아니다. 4. 관계 행정기관의 장은 해당 법률에 의한 물품의 수출·수입 요령 그 시행일 전에 지식경제부 장관이 통합하여 공고할 수 있도록 제출하여야  한다.',
 'answer': '대외무역법은 국내법으로서 국민의 국내 경제생활에 적용되는 법률이기 때문에 외국인이 국내에서 행하는 무역행위는 그 적용 대상이 아니다.'}

    # Exam dataset
Dataset({
    features: ['context', 'question', 'answer'],
    num_rows: 1430
})

# Term dataset
Dataset({
    features: ['context', 'question', 'answer'],
    num_rows: 15678
})

# Transcript dataset
Dataset({
    features: ['context', 'question', 'answer'],
    num_rows: 8885
})

# Concatenated dataset
Dataset({
    features: ['context', 'question', 'answer'],
    num_rows: 25993
})

    The combined dataset (training dataset) with the Q/A format is as above. About 26,000 Q/A pairs are expected to be used for training.

    Now, the dataset for fine-tuning is ready. Let’s check how this dataset is actually fed into the model.

    <bos><start_of_turn>user
Write a hello world program<end_of_turn>
<start_of_turn>model

    On the Huggingface website, you can find the model card for gemma-2-2b-it, which includes information on the chat template format and the definition of the model's prompt format (gemma-2-2b-it). This means that to ask questions to gemma, you need to create a prompt in a format that the model can understand.

    The start of the conversation is marked with <start_of_turn>, and the end of the conversation is marked with <end_of_turn>. The speakers are specified as the user and the model. Therefore, when asking a question to the model, the prompt should follow this format.

    def formatting_func(example):
    prompt_list = []
    for i in range(len(example['question'])):
        prompt_list.append("""<bos><start_of_turn>user
    다음 질문에 대답해주세요:
    {}<end_of_turn>
    <start_of_turn>model
    {}<end_of_turn><eos>""".format(example['question'][i], example['answer'][i]))
        return prompt_list

This document focuses on training the model using the Q/A dataset, so the approach will be to train the model in the manner of "for this type of question, respond in this way." Considering the previously mentioned chat template, you can write code in the format described above.

At this point, even if tokens are not explicitly included in the chat template, the model may attempt to generate more content beyond the delimiter. To ensure the model provides only an answer and then ends its turn, an <eos> token is added.

    <start_of_turn>user 다음 질문에 대답해주세요: '(관세)감축률(Reduction Rate)' 이라는 무역 용어는 어떤 의미인가요?<end_of_turn> <start_of_turn>model 관세를 감축하는 정도를 말함. 예를 들어 200%p에 관세감축률이 50%를 적용하면 감축 후 관세는 100%p가 됨. 극단적인 경우로 관세감축률이 100%이면 모든 관세는 감축 후에는 0%p가 됨.<end_of_turn>

    In actual training, examples like the one above will be used as input. Now, the dataset preparation for training is complete.

# Training
The training code is very simple. We use SFTTrainer, and as the base model, we use the gemma-2-2b-it model, which has been continually pretrained on SCM & trade datasets.

```python
model_id = "google/gemma-2-2b-it"
output_dir = 'QA_finetune/gemma-2-2b-it-lora128'
tokenizer = AutoTokenizer.from_pretrained(model_id, token=access_token)

model = AutoModelForCausalLM.from_pretrained(
            # "google/gemma-2-2b-it",
            "yonggeun/gemma-2-2b-it-lora128-merged",
            device_map="auto",
            torch_dtype=torch.bfloat16,
            token=access_token,
            attn_implementation="eager", # attn_implementation,
            cache_dir="./models/models",
        )


def formatting_func(example):
    prompt_list = []
    for i in range(len(example['question'])):
        prompt_list.append("""<bos><start_of_turn>user
다음 질문에 대답해주세요:
{}<end_of_turn>
<start_of_turn>model
{}<end_of_turn><eos>""".format(example['question'][i], example['answer'][i]))
    return prompt_list


def train(data):
    valid_set = data["test"]
    valid_set.save_to_disk('QA_finetune/valid_set/gemma-2-2b-it-lora128')

    lora_config = LoraConfig(
        r=256,
        lora_alpha=32,
        lora_dropout=0.05,
        bias="none",
        target_modules=["q_proj", "o_proj", "k_proj", "v_proj", "gate_proj", "up_proj", "down_proj"],
        task_type="CAUSAL_LM",
    )

    training_args = TrainingArguments(
        per_device_train_batch_size=2,
        warmup_steps=2,
        logging_steps=1,
        gradient_accumulation_steps=4,
        # num_train_epochs=3,
        num_train_epochs=3,
        learning_rate=2e-4,
        save_steps=100,
        fp16=False,
        bf16=True,
        output_dir=output_dir,
        push_to_hub=True,
        report_to="wandb"
    )

    trainer = SFTTrainer(
        model=model,
        tokenizer=tokenizer,
        train_dataset=data['train'],
        args=training_args,
        formatting_func=formatting_func,
        peft_config=lora_config,
        max_seq_length=max_length,
        packing= False,
    )

    model.config.use_cache = False

    print("Training...")
    trainer.train()
    print("Training done!")

    Evaluation

    Once the training is successfully completed, it is essential to evaluate the model's performance. This article focuses on evaluating Question Answering performance in a specific domain, which required different metrics than those typically used for benchmarking general models. In this article, the model was evaluated using SemScore and Truthfulness.

    SemScore: An evaluation method based on the semantic textual similarity between the target response and the model's response. (SemScore)

    Evaluating Truthfulness: This method measures truthfulness on a scale of 1 to 5 by providing the model's response and the target answer to an LLM. (Truthfulness)

    Fasttrack pipeline

    Now, let’s create a pipeline in FastTrack that will be used for model training. A pipeline is a unit of work used in FastTrack. Each pipeline can be represented as a collection of tasks, which are the smallest executable units. Multiple tasks within a single pipeline can have dependencies on each other, and their sequential execution is ensured based on these dependencies.

    Create Pipeline

    In the image above, find the blue '+' button to create a new pipeline.

    When creating a pipeline, you can choose the pipeline’s name and description, the location of the data repository to be used, and the environment variables that will be commonly applied in the pipeline. After entering the necessary information, click the "Save" button at the bottom to create the pipeline.

    Drag and create task

    Once a new pipeline is created, you can add a new task to the task template. Click on the "Custom Task" and drag it into the workspace below to create a new task.

    Enter information

    When creating a task, you need to enter the information required for task execution, as shown above. Write the task name and description clearly, and choose between a single node or multiple nodes. In this document, we will perform training on a single node, so we will select a single node.

    Next, you need to write the command. The command essentially runs the session. Make sure to specify the directory of the mounted V-folder correctly so that the script runs without errors. Most of the packages required for training are already installed in the session, but if additional packages need to be installed or there are version issues, you may need to reinstall the packages. In such cases, you can specify the required packages in the requirements.txt file, install them, and then run the other scripts.

    Resource configuration

    Next are the settings for the session, resources, and V-folder.

    Although the code in this article is written based on PyTorch, you can also choose other environments like TensorFlow, Triton server, etc.

    One of the advantages of FastTrack is its ability to utilize resources as efficiently as possible. Even within a single resource group, resources can be divided among multiple sessions, maximizing the resource utilization rate.

    For dataset preparation, GPU computation is not required, so it is acceptable not to allocate GPU resources. This allows you to run the code with minimal resources and allocate GPU resources to other sessions during this time, preventing GPU resources from remaining idle. Furthermore, if parallel model training is needed (e.g., when 10 GPUs are available and each training session requires 5 GPUs), you can train models in parallel. This approach helps reduce resource wastage and shortens training time.

    Select the V-folder where the prepared dataset and training code are correctly located.

    Duplicate or delete task

    By clicking the meatball menu icon (⋯) at the top right corner of the task block, you can duplicate or delete the created task.

    In FastTrack, you can set the order between multiple created tasks like this. This process involves adding dependencies between tasks. In some cases, you can set the next task to run only after several tasks are completed. In such cases, the next task will not proceed until all dependent tasks are finished. The completed example is shown above. In this article, we will proceed in the order of dataset preparation - fine-tuning - evaluation.

    If each task is defined correctly, click "Run" to execute the pipeline.

    On the left side of the FastTrack screen, you can see the pipelines you created. By clicking on them, you can monitor the currently running tasks and previously executed tasks in the pipeline task session.

    Monitoring jobs

    You can monitor the tasks through a screen like the one above. Each task proceeds in the specified order; once a previous task is completed, resources are allocated to start the session for the next task, and when the task is done, the session is terminated. There is also an option to skip tasks if needed. For example, in the image above, you can see that the fine-tuning task is running after skipping the dataset preparation task.

    Skipped tasks are shown in pink, running tasks are in light blue, and tasks scheduled to run are in yellow.

    Log checking

    By clicking the blue button next to each task's name, highlighted with a red square, you can check the logs of each task. This allows you to directly monitor the training progress. The logs appear the same as they would in a terminal, as shown in the screen above, allowing you to verify that the training is progressing correctly.

    Once the pipeline execution is successfully completed, you can check the results. In this document, the evaluation results are plotted and saved as /home/work/XaaS/train/QA_finetune/truthfulness_result.png.

    (Backend.AI's V-folder has a default directory structure of /home/work/~.)

    After training is complete, the result image is generated at the specified path.

    Result checking

    As shown above, you can see the successful execution of the pipeline by checking to the left of each task name.

    Result

    Now, let’s compare the results of the fine-tuned model with the base gemma-2-2b-it model.

    1. SemScore (Semantic text similarity between target response and model response, 1.00 is the best)

      | Base Model | Trained Model | |------------|---------------| | 0.62 | 0.77 |

    The SemScore of the trained model has increased (0.62 -> 0.77). This result indicates that the trained model can generate outputs that are more semantically similar to the target responses. In other words, the trained model has improved in generating responses that are closer to the intended target responses and more semantically consistent. As a result, the overall performance and reliability of the trained model have significantly improved.

    1. Truthfulness The trained model shows a trend of increasing high-score cases and decreasing low-score cases. Low scores (1, 2 points) decreased (1,111 -> 777), while high scores (4, 5 points) increased (108 -> 376). This indicates that the model's ability to identify domain information closer to the truth has improved, showing that the training was effective.

      Truthfulness result

    Conclusion

    In this article, we built a pipeline to train a model specialized in a specific domain using FastTrack, the MLOps platform of Backend.AI.

    Even though we utilized only some of FastTrack’s features, it allowed us to flexibly manage resources, freely configure tasks, reduce training time, and improve resource utilization. Moreover, we were able to train models stably in independent execution environments and monitor the execution information of pipeline jobs, enabling us to track resource usage and execution counts for each pipeline during training.

    In addition to the contents covered in this article, FastTrack supports a variety of additional features such as scheduling and parallel model training. For more information about other features of FastTrack, you can refer to the blog posts written by Kang Ji-hyun and Kang Jung-seok, linked below.

    Although we did not fully utilize all of FastTrack's features, its flexible resource management and free task configuration helped shorten training time and increase resource utilization rates. Furthermore, it provided a stable training environment and allowed us to monitor resource usage and execution frequency within each pipeline through pipeline job execution information. FastTrack also supports many other functionalities such as scheduling and parallel model training. You can find more information about FastTrack in the documents below.

    Backend.AI MLOps 플랫폼 FastTrack을 소개합니다.

    FastTrack 길라잡이: 모델 학습 결과 알림 받기

    26 September 2024

    Read more

  • FastTrack Guide: Receiving Notifications for Model Training Results

    By Jeongseok Kang

    From the now-classic AlexNet to various large language models (LLMs) that are garnering a lot of attention these days, we train and evaluate various models to suit our needs. However, realistically, it's difficult for us to gauge when the training will end until we run the model multiple times and gain experience.

    Backend.AI's excellent scheduling minimizes GPU idle time and allows model training to run even while we sleep. Then, what if we could receive the results of a model that finished training while we were asleep? In this article, we'll cover how to receive model training results as messages using the new feature of FastTrack and Slack.

    This article is based on the Backend.AI FastTrack version 24.03.3.

    Before We Start

    This article does not cover how to create a Slack App and Bot. For detailed information, we recommend referring to the official documentation.

    Creating a Pipeline

    Let's create a pipeline for model training. A pipeline is a unit of work used in FastTrack. Each pipeline can be expressed as a collection of tasks, the minimum execution unit. Multiple tasks included in a single pipeline can have interdependencies, and they are executed sequentially according to these dependencies. Resource allocation can be set for each task, allowing flexible resource management.

    When an execution command is sent to a pipeline, it is executed by replicating the exact state at that point, and this unit is called a pipeline job. Multiple pipeline jobs can be run from a single pipeline, and each pipeline job is generated from a single pipeline.

    Create Pipeline button

    Click the Create Pipeline button ("+") at the top of the pipeline list.

    Creating a Pipeline

    You can specify the pipeline's name, description, location of the data store to use, environment variables to be applied commonly across the pipeline, and the method of pipeline initialization. Enter the name "slack-pipeline-0", and then click the "Create" button at the bottom to create the pipeline.

    Creating Tasks

    Dragging a Task

    You can see that the new pipeline has been created. Now let's add some tasks. From the task template list (Task templates) at the top, drag and drop the "Custom Task" block onto the workspace below.

    Entering the Task's Actions

    A task details window appears on the right where you can enter the task's specifics. You can give it a name like model-training-task to indicate its role, and set it to use the pytorch:1.11-py38-cuda11.3 image for model training. Since actual model training can take a long time, for this example, we'll have it execute the following simple commands:

    # Pause for 3 seconds to increase the execution time.
sleep 3
# Create a `result.txt` file in the pipeline-dedicated folder. Assume this is the accuracy of the trained model.
echo "0.$RANDOM" > /pipeline/outputs/result.txt

    Creating a Task (1)

    Finally, enter the resource allocation for the task, and then click the "Save" button at the bottom to create the task.

    Dragging Another Task

    You can see that the model-training-task has been created in the workspace. This time, to create a task that reads the value from the result.txt file saved earlier and sends a Slack notification, drag another "Custom Task" block into the workspace below.

    Entering the Task-level Environment Variable `SLACK_TOKEN`

    For this task, set the name to slack-alarm-task, and enter the following script to send a notification to Slack:

    pip install slack-sdk
python -c '
import os
from pathlib import Path
from slack_sdk import WebClient
SLACK_BOT_TOKEN = os.environ.get("SLACK_TOKEN")
JOB_ID = os.environ.get("BACKENDAI_PIPELINE_JOB_ID")
def main():
    result = Path("/pipeline/input1/result.txt").read_text()
    client = WebClient(token=SLACK_BOT_TOKEN)
    client.chat_postMessage(
        channel="#notification",
        text="Pipeline job({}) finished with accuracy {}".format(JOB_ID, result),
    )
if __name__ == "__main__":
    main()
'

    The code above uses two environment variables: SLACK_TOKEN and BACKENDAI_PIPELINE_JOB_ID. Environment variables in the BACKENDAI_* format are values automatically added by the Backend.AI and FastTrack systems, where BACKENDAI_PIPELINE_JOB_ID represents the unique identifier of the pipeline job in which each task is running.

    The other environment variable, SLACK_TOKEN, is a task-level environment variable. This feature allows you to manage and change various values without modifying the code.

    Creating a Task (2)

    After allocating appropriate resources for the slack-alarm-task, click the "Save" button at the bottom to create the task.

    Adding Task Dependencies

    Adding Task Dependencies

    Now there are two tasks (model-training-task and slack-alarm-task) in the workspace. Since slack-alarm-task should be executed after model-training-task completes, we need to add a dependency between the two tasks. Drag the mouse from the bottom of the task that should run first (model-training-task) to the top of the task that should run later (slack-alarm-task).

    Running the Pipeline

    Running the Pipeline (1)

    You can see an arrow connecting from model-training-task to slack-alarm-task, indicating that the dependency has been added. Now, to run the pipeline, click the "Run" button in the top right.

    Running the Pipeline (2)

    Before running the pipeline, you can review a brief summary of it. After confirming the presence of the two tasks, click the "Run" button at the bottom.

    Running the Pipeline (3)

    The pipeline was successfully run, and a pipeline job was created. Click "OK" at the bottom to view the pipeline job information.

    Pipeline Job

    The pipeline job was created successfully. You can see that the model training (model-training-task) has completed, and slack-alarm-task is running.

    Receiving Slack Notification

    Slack Notification (1)

    Slack Notification (2)

    You can see that the pipeline job execution results have been delivered to the user via Slack. Now we can sleep soundly.

    30 May 2024

    Read more

  • 23.09: September 2023 Update

    By Lablup

    23.09: September 2023 update

    In the second half of 2023, we released 23.09, a major release of Backend.AI. In 23.09, we've significantly enhanced the development, fine-tuning, and operational automation of generative AI. We've automatically scaled and load-balanced AI models based on workload, expanded support for various GPUs/NPUs, and increased stability when managing a single node as well as 100-2000+ nodes. The team is working hard to squeeze every last bit out of it. Here are the main improvements since the last [23.03 July update] (/posts/2023/07/31/Backend.AI-23.03-update).

    Backend.AI Core & UI

    • The Backend.AI Model Service feature has been officially released. You can now use Backend.AI to more efficiently prepare environments for inference services as well as training of large models such as LLM. For more information, see the blog Backend.AI Model Service sneak peek.
    • Added the ability to sign in to Backend.AI using OpenID single sign-on (SSO).
    • If your kernel image supports it, you can enable the sudo command without a password in your compute session.
    • Support for Redis Sentinel without HAProxy. To test this, we added the --configure-ha setting to the install-dev.sh file.
    • Added the ability to use the RPC channel between Backend.AI Manager and Agent for authenticated and encrypted communication.
    • Improved the CLI logging feature of Backend.AI Manager.
    • Fixed an issue where Manager could not make an RPC connection when Backend.AI Agent was placed under a NAT environment.
    • The Raft algorithm library, riteraft-py, will be renamed and developed as raftify.
    • Support for the following new storage backends
      • VAST Data
      • KT Cloud NAS (Enterprise only)

    Backend.AI FastTrack

    • Improved UI for supporting various heterogeneous accelerators.
    • Deleting a VFolder now uses an independent unique ID value instead of the storage name.
    • Upgraded Django version to 4.2.5 and Node.js version to 20.
    • Added pipeline template feature to create pipelines in a preset form.
    • If a folder dedicated to a pipeline is deleted, it will be marked as disabled on the FastTrack UI.
    • Improved the process of deleting pipelines.
    • Added a per-task (session) accessible BACKENDAI_PIPELINE_TASK_ID environment variable.
    • Actual execution time per task (session) is now displayed.

    Contribution Academy

    Especially in the past period, the following code contributions were made by junior developer mentees through the 2023 Open Source Contribution Academy organized by NIPA.

    • Created a button to copy an SSH/SFTP connection example to the clipboard.
    • Refactored several Lit elements of the existing WebUI to React.
    • Wrote various test code.
    • Found and fixed environment variable and message errors that were not working properly.

    Backend.AI is constantly evolving to provide a more powerful and user-friendly experience while supporting various environments in the AI ecosystem. Stay tuned for more updates!
    Make your AI accessible with Backend.AI!

    This post is automatically translated from Korean

    26 September 2023

    Read more

  • 23.03: July 2023 Update

    By Lablup

    23.03: July 2023 update

    A wrap-up of the ongoing updates to Backend.AI 23.03 and 22.09. The development team is working hard to squeeze every last bit out.

    Here are the most important changes in this update

    • Enhanced storage manageability: Added per-user and per-project storage capacity management (quotas) with VFolder v3 architecture.
    • Expanded NVIDIA compatibility: Support for CUDA v12 and NVIDIA H100 series.
    • Extended hardware compatibility: Support for WARBOY accelerators from FuriosaAI.

    Backend.AI Core & UI

    • Supports CUDA v12 and NVIDIA H100 series.
    • Supports the WARBOY accelerator, the first NPU from FuriosaAI company.
    • Added storage capacity management function (Quota) by user and project by applying VFolder v3 architecture.
      • However, it is limited to storage that supports Directory Quota.
    • Fixed an error that caused multi-node cluster session creation to fail.
    • Fixed an error where a compute session in the PULLING state was incorrectly labeled as PREPARING.
    • Fixed an error in which the CLONING state was incorrectly displayed when cloning a data folder with the same name when multiple storage devices have the same folder.
    • Improved the web terminal of a compute session to use zsh as the default shell if the zsh package is installed in the kernel image.
    • Added the ability to know the health status of the (managed) storage proxy and event bus.

    Backend.AI FastTrack

    • Added the ability to set multi-node cluster mode by task.
    • Fixed an error where environment variables set in .env were not applied to the frontend.
    • Fixed an error recognizing out-of-date when accessing with a mobile browser.
    • Added a field to show the cause message when a task-specific error occurs.
    • Fixed other editor-related issues.

    Backend.AI is constantly evolving to provide a more powerful and user-friendly experience while supporting various environments in the ever-changing AI ecosystem. Stay tuned for more updates!
    Make your AI accessible with Backend.AI!

    31 July 2023

    Read more

  • 23.03: May 2023 Update

    By Lablup

    A recap of the ongoing updates to Backend.AI 23.03 and 22.09. The development team is working hard to squeeze every last bit out.

    Here are the most important changes in this update:

    • Expanded hardware compatibility: Expanded hardware compatibility with support for ATOM accelerator idle checking and Dell EMC storage backends from Rebeillons.
    • High-speed upload enhancements: Introduced SFTP functionality to support high-speed uploads to storage.
    • Development Environment Enhancements: Enhanced the development environment by allowing sessions to be accessed in remote SSH mode from local Visual Studio Code.
    • Increased manageability: Improved the user interface for administrators to make it easier to set up AI accelerators and manage resource groups.

    Backend.AI Core & UI

    • Added support for idle state checking of ATOM accelerators.
    • Introduced SFTP functionality to support high-speed uploads directly to storage.
    • Added ability to force periodic password updates based on administrator settings.
    • Added an upload-only session (SYSTEM) tab.
    • Added Inference type to the allowed session types.
    • Added the ability to connect to a session in remote SSH mode from local Visual Studio Code.
    • Added support for uploading folders from Folder Explorer.
    • Improved the display of the amount of shared memory allocated when creating a session.
    • Added support for Dell EMC storage backend.
    • Improved the accuracy of container memory usage measurement.
    • Improved the ability to run multiple agents concurrently on a single compute node.
    • Added project/resource group name filter for administrators.
    • Added user interface for administrators to set various AI accelerators, including GPUs, in resource presets/policies.
    • Added a user interface for administrators to display the allocation and current usage of various accelerators, including GPUs.
    • Added a user interface for administrators to set the visibility of resource groups.
    • Provided a user interface for administrators to view the idle-checks value per session.
    • Added recursion option when uploading vfolders in the CLI, and improved relative path handling.
    • Added a recursive option in the CLI to terminate sessions with dependencies on specific session termination at once.
    • Added a new mock-accelerator plugin for developers, replacing the old cuda-mock plugin.
    • Added status and statistics checking API for internal monitoring of the storage proxy for developers.

    Backend.AI FastTrack

    • Improved searching for vfolders by name when adding pipeline modules.
    • Added an indication to easily recognize success/failure after pipeline execution.

    Backend.AI Forklift

    • Bug fixes and stability improvements.
    • Support for deleting build job history.
    • Supports pagination of the build task list.

    Backend.AI is constantly evolving to support a variety of environments in the ever-changing AI ecosystem, while providing a more robust and user-friendly experience. Stay tuned to see what's next!

    Make your AI accessible with Backend.AI!

    This post is automatically translated from Korean

    31 May 2023

    Read more

  • 23.03: March 2023 Update

    By Lablup

    23.03: 2023년 3월 업데이트

    We're excited to announce version 23.03.0, the first major release of Backend.AI for 2023. Some features will continue to be rolled out in subsequent updates.

    Specifically in this update:

    • Support for the 'inference' service with a new computation session type.
    • Support for 'model' management with a new storage folder type.
    • Support for managing storage capacity on a per-user and per-project basis.
    • Significant improvements to FastTrack's pipeline versioning and UI.

    Backend.AI Core & UI (23.03)

    • Added model management and inference session management capabilities.
      • More advanced inferential endpoint management and network routing layers will be added in subsequent updates.
    • The codebase has been updated to be based on Python 3.11.
    • Introduced React components to the frontend and leveraged Relay to introduce a faster and more responsive UI.
    • Full support for cgroup v2 as an installation environment, starting with Ubuntu 22.04.
    • Updated the vfolder structure to v3 for storage capacity management on a per-user and per-project basis.
    • Kernel and sessions are now treated as separate database tables, and the state transition tracking process has been improved to work with less database load overall.
    • Improved the way the agent displays the progress of the image download process when running a session.
    • Improved the display of GPU usage per container in CUDA 11.7 and later environments.
    • Scheduling priority can be specified by user and project within each resource group.
    • Supports two-factor authentication (2FA) login based on one-time password (TOTP) to protect user accounts.
    • Support for users to register their own SSH keypair for session access.
    • Supports user interfaces for Graphcore IPUs and Rebellions ATOM devices.

    Backend.AI Forklift (23.03)

    • Added Dockerfile templates and advanced editing capabilities.
    • Support for creating container images for inference.
    • Extended image management capabilities to work with the Harbor registry.

    Backend.AI FastTrack (23.03)

    • Storage folder contents can be viewed directly from the FastTrack UI.
    • Improved session state synchronisation with Core to event-based.
    • You can set the maximum number of iterations for a pipeline schedule.
    • If a task fails to execute, the pipeline job is automatically cancelled instead of waiting.
    • Added pipeline versioning. You can track the shape history of your pipeline, and you can recall the contents at a specific point in time to continue working on it.
    • You can modify pipelines in YAML format directly through the code editor.

    개발 및 연구 프레임워크 지원

    • Supports TensorFlow 2.12, PyTorch 1.13
    • Support for NGC (NVIDIA GPU Cloud) TensorFlow 22.12 (tf2), NGC PyTorch 22.12, NGC Triton 22.08
    • Added python-ff:23.01 image, which provides the same libraries and packages as Google Colab

    In addition to what we've listed above, we've included many bug fixes and internal improvements.
    Stay tuned for more to come!

    This post is automatically translated from Korean

    31 March 2023

    Read more

  • Introducing FastTrack: Backend.AI MLOps Platform

    By Jihyun Kang

    Introducing FastTrack, the MLOps Platform of Backend.AI. FastTrack allows you to organize each step of data preprocessing, training, validation, deployment, and inference into a single pipeline. FastTrack makes it easy for you to customize each step as you build your pipeline. In this article, we'll explain why you need an MLOps platform, how Backend.AI FastTrack came to be, and what makes itself really unique.

    Rise of MLOps Platforms

    Over the past few years, the IT industry, as well as most industries undergoing digital transformation, has been working hard to adopt AI to make meaningful predictions from scattered data and respond to rapidly changing markets. In order to make a good use of AI in this process, it is necessary to respond to various stages such as model training and optimization, hardware introduction considering data I/O, model version management, etc. The concept of MLOps (Machine Learning Operations) emerged from this. If you are unfamiliar with the concept, we recommend that you skim our 'MLOps series' before reading this article.

    FastTrack: History

    In 2019, we added the Backend.AI pipeline as a beta release to address the demand for DevOps pipelines. We developed and tested the ability to simplify the process of creating and managing complex pipelines, and to operate unidirectional pipelines that split into two or more paths in the middle. However, with the rise of the MLOps concept and the proliferation of various pipeline solutions such as AirFlow, MLFlow, and KubeFlow, we shifted our development direction to integrating and supporting open source pipeline tools instead of developing pipeline features as a full-fledged feature.

    Meanwhile, AI development pipelines have became increasingly complexed, and became clear that open-source MLOps pipeline tools were unable to meet the diverse needs of the users. At this point, we decided to revive the pipeline feature of Backend.AI. During the process of revitalizing and prototyping the Backend.AI pipeline, we changed the direction of development to a MLOps pipeline solution that works with the Backend.AI cluster, but stands independently, so that we could directly address our user requests.

    With such a colorful history, Lablup's AI/MLOps solution is called 'FastTrack'. This name came from the airport or logistics, a lane which expedites passenger or custom clearance. FastTrack became available with Backend.AI 22.09, and still being tested to meet our customer standards.

    FastTrack: What it is

    FastTrack is a machine learning workflow platform that enables users to tailor multiple work units based on Backend.AI clusters and execute them as a Directed Acyclic Graph (DAG). Users can run sessions for each stage of the machine learning pipeline, linked through pre- and post-relationships, allowing them to integrate steps like data preprocessing, training, validation, deployment, monitoring, and optimization into a unified workflow as needed. This means users can more efficiently build and reuse models by structuring sessions into workflows and automatically scheduling them after each phase, rather than manually crafting them in a conventional Backend.AI cluster.

    FastTrack: Structure and features

    FastTrack categorizes workflow templates as pipelines, executes workflows to pipeline jobs, divides the units of work in a workflow into tasks, and the units of work that are to be executed into task instances. The flowchart following outlines the step-by-step progression of work within FastTrack.

    Pipeline

    A pipeline is a structured collection of data and tasks, represented by a Directed Acyclic Graph (DAG). In setting up an AI workflow, constructing a pipeline prompts FastTrack to create a specific folder in your Backend.AI cluster dedicated to pipelines. This setup facilitates the monitoring of training progress via artifacts. FastTrack streamlines the modification of task relationships with an intuitive drag-and-drop interface, allowing for immediate visual feedback in the form of a schematic flow and verification through a YAML file. Moreover, managing pipelines in YAML format allows for easy export, import, and sharing among users.

    Pipeline Job

    Within the FastTrack GUI, the progress of job units is indicated by the color of the nodes associated with each unit. Similar to pipelines, the information and relationships of the task instances being configured in YAML are managed. Upon completion of all task instances, the pipeline job's status is displayed as either successful or failed.

    Task

    A task is the smallest unit of execution in a pipeline that allows you to allocate resources by purpose. For example, sole task for model training can dedicate a lot of GPU resources, to use resources more efficiently, as opposed to preprocessing. You can also specify the execution environment. Based on the images supported by the Backend.AI cluster, you can use images such as TensorFlow, PyTorch, Python 3.x, NGC TensorFlow, NGC PyTorch, etc. without Docker building process. You can also mount virtual folders created by the Backend.AI cluster on a per-task basis as needed.

    Task Instance

    Task instances are physical objects created when a pipeline job is created, based on the task informations that makes up the pipeline. Executing an AI workflow means that the task instances that make up the pipeline job are executed according to the specified preceding and following relationships. Task instances currently have a 1:1 correspondence with Sessions in the Backend.AI cluster, equating the state of a session with the state of a task instance, but we plan to expand beyond sessions to other units of execution in the near future.

    Wrap up

    So far, we've covered MLOps with an introduction to FastTrack, the Backend.AI MLOps platform. The latest release of Backend.AI FastTrack is version 22.09 (in the time of Nov.2022). Our development plans include a range of user-friendly features, such as debugging pipelines, creating dependencies between pipelines, optimizing the usage of resources for tasks, and providing support for GitHub-based model and data repositories. True to Lablup's vision of empowering anyone to develop and use AI models from anywhere, FastTrack will simplify the process of building automated models. We look forward to your interest in our future endeavors.

    29 November 2022

    Read more

We're here for you!

Complete the form and we'll be in touch soon

Contact Us

Headquarter & HPC Lab

Namyoung Bldg. 4F/5F, 34, Seolleung-ro 100-gil, Gangnam-gu, Seoul, Republic of Korea

© Lablup Inc. All rights reserved.

Privacy PolicyTerms of Use
